1000W Raycus Continuous Fiber Laser Source Welding Cutting
Excellent beam quality.
High reliability.
High power stability.
Description
1000W Raycus Continuous Fiber Laser Source
Product Introduction
Compared with traditional laser source, continuous fiber laser sources have higher photoelectric conversion efficiency and lower power consumption and better beam quality. The fiber laser source is compact and can be used at any time. Because of its flexible laser output mode, it can be easily integrated with system equipment.
Product Advantages
1. Excellent beam quality.
2. High reliability.
3. High power stability.
4. Continuously adjustable power, fast switching response.
5. Maintenance-free operation.
6. High electro-optical conversion efficiency.
7. High modulation frequency.
Product Application
RFL-C1000 is suitable for industrial cutting, welding and 3D printing. This single-module continuous fiber laser can not only meet the diverse needs of customers, but also provide personalized professional customization. At present, QBH is selected as the output connector of the laser, which has multiple control modes and good compatibility.
Parameters
| Optical properties | |
| Rated output power (W) | 1000 |
| Working mode | continuous/modulation |
| Power adjustment range (%) | 10~100 |
| Center wavelength (nm) | 1080±5 |
| Output power instability (%) | ±1.5 |
| Modulation frequency (Hz) | 1~20,000 |
| Red light indicating output power (mW) | 0.5~1 |
| QBH output head optical output characteristics | |
| Beam quality M² | 1.5 |
| Fiber core diameter (μm) | 25 (14, 20, 50, 100, 200 optional) |
| Output optical cable length (m) | 20 |
| Electrical characteristics | |
| Working voltage | 220±20% V AC, 50/60Hz |
| Numerical aperture (NA) | 0.11 |
| Maximum power consumption (W) | 4000 |
| Control method | RS-232/AD/Ethernet |
| Other features | |
| Appearance size (W×H×D) (mm) | 485×183×723 |
| Weight (kg) | <40 |
| Working environment temperature range (℃) | 10~40 |
| Working environment humidity range (%) | <70 |
| Storage temperature (℃) | -10~60 |
| Cooling method | water cooling |
